    Stud ASTM A108 Perno Shear Connector For Bridge Building Steel Decking

    Ask Lasest Price
    Brand Name : BOZEX
    Model Number : BZX.B04487
    Certification : ISO9001,CE, SGS, BV
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 50Million pcs per day
    Delivery Time : 5-8working days
    • Product Details
    • Company Profile

    Stud ASTM A108 Perno Shear Connector For Bridge Building Steel Decking

    Shear Stud ASTM A108 Perno Shear Connector For Bridge Building Steel Decking ISO 13918/AWS D1.1/BS 5400

    Product Application

    Our shear connector used for Mulit-floor & high rising bulidings, bridge construction,airport,stadium, exhibitions, conference centre, railway station.We dedicated to be expertise in struture connection solutions.

    Main Features

    1) Shear Connector Studs are designed to tie the concrete to the steel beams and to resist shear loadings between the concrete slab and steel beam in composite construction.

    2) Shear studs are used in stud welding to secure steel framed buildings to create a shear connection between the steel and the concrete. We supply and fix all available sizes of welded shear studs for through deck and straight to steel welding.


    3) All our products meet the current standards and specifications.


    specification:

    Mechanical Properties Of Shear Stud Connector
    Hot sell StandardTensile strengthYield strengthElongation
    EN ISO 13918 SD1≥450 Mpa≥350 Mpa≥15%
    AWS D1.1≥450 Mpa≥350 Mpa≥15%
    BS 5400≥495 Mpa≥385 Mpa≥18%

    Chemical Component Of Material (%)
    MaterialCSiMnPSAl
    SWRCH15A0.13-0.18≤0.100.30-0.60≤0.035≤0.035≥0.020
    SWRCH18A0.15-0.20≤0.100.60-0.90≤0.030≤0.035≥0.020
    Q345D≤0.18≤0.50≤1.70≤0.030≤0.025≥0.015

    1.StainlessSteel:SS201,SS303,SS304,SS316,SS410

    2.Steel: 35CrMoA, 35CrMo, 3
    3.Carbon Steel: 1010,1035,1045

    4.Aluminum or Aluminum Alloy

    5.Brass:

    A2-70,A2-70, A4-70,A4-80,2205,2507

    Class 4.8, 5.8, 6.8, 8.8, 10.9, 12.9 and etc.

    A307 Grades A, B, C

    Plain, Zinc Plated(Clear/Blue/Yellow/Black), Black oxide, Nickel, Chrome, H.D.G and etc.
    UNC,UNF,UEF,UN,UNS
    ISO, DIN, ANSI, JIS, BS and Non-standard
    ISO9001,CE, SGS, BV
    1. Competitive price; 2. OEM service available
    Bulk in cartons (25kg Max.)+wood Pallet or according to customer special demand
    FOB, CIF, CFR, L/C, or others.
    by sea, by air or by express service
    7-15 work days after order confirmed

    Advantages

    1. Our company have more than 15 years experience in the Stainless Steel Screws field.

    2. We have Professional experienced engineers, sales and overseas engineers.

    3. We have automatically generate machines produce the screws, Bolts, Nuts, Washers and so on .

    4. Our high productivity can make sure your quickly delivery time


    M8X1.25X45mm Titanium Stud Kit Exhaust Manifold Studs Nut Kit Details
